EKI-2000 Series

EKI-2428G-4CI

24GE+4G组合非托管以太网交换机，19“机架式，-40~75℃

  • 24个千兆以太网口+4个千兆光电复用Combo端口
  • SFP 插槽可进行简单灵活的光纤扩展
  • 提供8K MAC地址
  • 提供冗余 12 ~ 48 VDC 电源输入
  • 支持-40~70°C工作温度

认证：

技术资源链接：

产品型录 Download 3D Model 技术文件下载
  • 24GE+4G组合非托管以太网交换机，19“机架式，-40~75℃

规格

Certification
EMI
  • CE, FCC, EN55022 Class A
EMS
  • EN 61000-4-2 (Level 3), EN 61000-4-3 (Level 3), EN 61000-4-4 (Level 3), EN 61000-4-5 (Level 3), EN 61000-4-6 (Level 3), EN 61000-4-8 (Level 3)
Safety
  • UL 61010-2-201
Environment
Temperature (Min. Operating)
  • -40°C (-40°F)
Temperature (Max. Operating)
  • 70°C (158°F)
Operating Temperature
  • -40 ~ 70°C (-40 ~ 158°F)
Storage Temperature
  • -45 ~ 85°C (-40 ~ 185°F)
Ethernet Communication
Fiber Port Number
  • 4 (combo)
Fiber Port Interface
  • SFP
Fiber Port Connector Type
  • SFP cage
Fiber Transmission Distance
  • Up to 110 km
Fiber Transmission Speed
  • 100/1000 Mbps
RJ-45 Port Number
  • 24 + 4 (combo)
RJ-45 Port Connector Type
  • RJ-45
RJ-45 Transmission Distance
  • 100 m
RJ-45 Transmission Speed
  • 10/100/1000 Mbps
Mechanism
Mounting (DIN-rail)
  • -
Mounting (Stack)
  • -
Mounting (Panel)
  • -
Mounting (Wall)
  • -
Mounting (Rack Mount)
  • Yes
Mounting (Pole Mount)
  • -
Dimensions (W x H x D)
  • 438 x 43.6 x 259.2 mm (17.24 x 1.71 x 10.2 in.)
Enclosure (Plastic)
  • -
IP Rating
  • IP30
Weight
  • 3.8 kg
PoE Information
PoE Port Number
  • -
PoE Budget
  • -
PoE Output
  • -
Support PoE
  • No
Power
Power Connector Type
  • 4-pin removable screw terminal (power & relay)
Power Consumption
  • 20W
Power Input (AC)
  • -
Power Input (DC)
  • 12 ~ 48 VDC (8.4 ~ 52.8 VDC) redundant dual inputs
Power Input (PoE)
  • -
Power Operating Current
  • 0.83A @ 24 V
Switch Properties
Jumbo Frame
  • 9,216 bytes
MAC Table Size
  • 8K
Packet Buffer Size
  • 4.1M bit
Switch Fabric Speed
  • 56Gbps
Warranty
Warranty Period
  • 5 years
Protection
Overload Current
  • Present
Reverse Polarity
  • Present

特点和优势


Advantech's EKI-2000 Series are the best deal offer for your Ethernet connections. Their super-slim IP30 metal casing design provides high reliability to quickly deliver continuous data transmission with high degree of security, making them an ideal option for your Ethernet solution.

Contact Us

Unmanaged Switch Plus Function Beyond Simple Connectivity

Unmanaged switch PLUS is a product concept that includes several innovative series. It introduces intelligent added features tailored for OT engineers, solving real-world challenges without IT complexity. Designed to enhance productivity, it keeps networking simple and effective in industrial environments.

LEARN MORE
High Versatile Switch Products

High Versatile Switch Products

  • Ranging from 5 to 28 ports. More than 30 skus.
  • Support din rail, wall mount or rack mount design
  • Support fast Ethernet or gigabit transmission
  • Optional fiber ports help you conquer the distance boundary
  • PoE functionality serves power and data transmission with one cable
Download Selection Guide
Plug-and-Play

Plug-and-Play

  • No setting efforts
  • No compatibility issues
  • Goes along with any network infrastructure
  • Slim size for instant installation with minimum costs and efforts, allowing users to upgrade to an intelligent plant at ease
Mini 8-cm Ethernet Switch
Robust Communication Solutions

Robust Communication Solutions

  • Super slim IP30 metal casing provides reliable & compact management
  • Support wide operating temperatures from -40 to 75oC
