超紧凑ARK-1000系列

ARK-1125H

Intel®处理器N200 QC SoC，带双HDMI、双GbE、双串行端口、双CANBus、远程开关、USB x4

  • Intel® 处理器 N-series N200 QC SoC
  • DDR5-4800 SO-DIMM 内存支持最高16G
  • 双 HDMI独立显示支持4K分辨率
  • M.2 E Key, B Key 和M Key 用于存储和无线模块安装
  • TPM系统安全选项
  • 支持宽温运行-30 ~ 60 °C
  • 12V lockable DC jack 电源输入
  • 支持研华 DeviceOn

认证：

技术资源链接：

产品型录 Download 3D Model 技术文件下载
  • Intel®处理器N200 QC SoC，带双HDMI、双GbE、双串行端口、双CANBus、远程开关、USB x4

规格

Processor
CPU
  • Intel® Processor N200
  • Intel® Processor N200
Core Number
  • 4
  • 4
Frequency
  • 1.0GHz, Max Turbo Frequency up to 3.7GHz
  • 1.0GHz, Max Turbo Frequency up to 3.7GHz
BIOS
  • AMI EFI 256 Mbit
  • AMI EFI 256 Mbit
Memory
Technology
  • DDR5 up to 4800MHz
  • DDR5 up to 4800MHz
Max. Capacity
  • 16 GB
  • 16 GB
Socket
  • 1 x 262-pin SO-DIMM
  • 1 x 262-pin SO-DIMM
ECC Support
  • No
  • No
Graphics
HDMI
  • 2
  • 2
Dual Display
  • Yes, HDMI + HDMI , both display support 4K2K resolution
  • Yes, HDMI + HDMI , both display support 4K2K resolution
Ethernet
Controller
  • 2
  • 2
LAN1
  • 10/100/1000/2500 Mbps Intel i226 GbE, support Wake On LAN
  • 10/100/1000/2500 Mbps Intel i226 GbE, support Wake On LAN
LAN2
  • 10/100/1000/2500 Mbps Intel i226 GbE, support Wake On LAN
  • 10/100/1000/2500 Mbps Intel i226 GbE, support Wake On LAN
Audio
Main System
  • Realtek ALC888S, High Definition Audio, Line-out, Mic-in
  • Realtek ALC888S, High Definition Audio, Line-out, Mic-in
I/O Interface
Serial Port
  • 2 x RS-232/422/485 port with auto flow control
  • 2 x RS-232/422/485 port with auto flow control
USB Interface
  • 2 x USB 3.2, 2 x USB 2.0
  • 2 x USB 3.2, 2 x USB 2.0
GPIO
  • 8-bit
  • 8-bit
Expansion
M.2
  • 2x, including 1x M.2 2230E key, 1x M.2 2280 B key with nano SIM holder
  • 2x, including 1x M.2 2230E key, 1x M.2 2280 B key with nano SIM holder
CAN Bus
  • 2
  • 2
Others
Watchdog timer
  • 255 levels timer interval, setup by software
  • 255 levels timer interval, setup by software
TPM
  • TPM 2.0 built in
  • TPM 2.0 built in
Storage
SATA and PCIe/NVMe
  • 2x, including 1x M.2 2230 E key (PCIe x1) and 1x M.2 2280 B key (PCIe x1)
  • 2x, including 1x M.2 2230 E key (PCIe x1) and 1x M.2 2280 B key (PCIe x1)
Software Support
Microsoft Windows
  • Windows 10
  • Windows 10
Linux
  • Ubuntu 22.04
  • Ubuntu 22.04
Power
Power Type
  • AT/ATX
  • AT/ATX
Input Voltage
  • 12 VDC power input
  • 12 VDC power input
Power Adaptor
  • Input: 100-240Vac, Output 12Vdc, 60W
  • Input: 100-240Vac, Output 12Vdc, 60W
Power Consumption
Max.
  • 29.18W
  • 29.18W
Typical
  • 10.54W
  • 10.54W
Mechanical
Construction
  • Aluminum housing
  • Aluminum housing
Dimensions
  • 133 x 46.4 x 94.2mm (5.24" x 1.83" x 3.71")
  • 133 x 46.4 x 94.2mm (5.24" x 1.83" x 3.71")
Mounting
  • DIN-rail/Wall Mount
  • DIN-rail/Wall Mount
Weight
  • 0.7 kg (1.55 lb)
  • 0.7 kg (1.55 lb)
Environment
Relative Humidity
  • 95% @ 40° C (non-condensing)
  • 95% @ 40° C (non-condensing)
Operating Temperature
  • With extended temperature peripherals: -30 ~ 60 °C (-22 ~ 140 °F) with 0.7m/s air flow
  • With extended temperature peripherals: -30 ~ 60 °C (-22 ~ 140 °F) with 0.7m/s air flow
Storage Temperature
  • - 40 ~ 85° C (-40 ~185° F)
  • - 40 ~ 85° C (-40 ~185° F)
Vibration During Operation
  • 3 Grms, IEC60068-2-64, random, 5~500 Hz, 1hr/axis
  • 3 Grms, IEC60068-2-64, random, 5~500 Hz, 1hr/axis
Shock During Operation
  • 30G, IEC60068-2-27, half sine, 11m duration
  • 30G, IEC60068-2-27, half sine, 11m duration
Certification
EMC
  • CE, FCC, CCC, BSMI
  • CE, FCC, CCC, BSMI
Safety Certifications
  • CB, UL, CCC, BSMI
  • CB, UL, CCC, BSMI
